Katech ZR1/LS9X/LS9R Clutch Alignment Tool

Katech ZR1/LS9X/LS9R Clutch Alignment Tool

Clutch Disc Alignment for Compatible ZR1, LS9X, and LS9R Twin-Disc Clutch Assemblies.

The Katech ZR1/LS9X/LS9R Clutch Alignment Tool helps position the clutch discs during installation of compatible twin-disc clutch assemblies. Proper alignment supports transmission input shaft installation through both clutch discs.

Features & Benefits

• Designed for Compatible ZR1, LS9X, and LS9R Twin-Disc Clutches
• Helps Align Both Clutch Discs During Assembly
• Supports Transmission Installation by Positioning the Clutch Disc Hubs

Technical Specifications

• Product Type: Clutch Alignment Tool
• Clutch Configuration: Twin-Disc
• Applications: Compatible ZR1, LS9X, and LS9R Clutch Assemblies

What's Included

• One Katech ZR1/LS9X/LS9R Clutch Alignment Tool

Fitment & Installation Notes

For use with compatible ZR1, LS9X, and LS9R twin-disc clutch assemblies. Confirm the clutch configuration before ordering; this tool is not presented as a universal fit for all twin-disc clutches.

• Follow the Clutch Manufacturer's Assembly Instructions
• Verify Correct Disc Orientation and Alignment Before Tightening the Clutch Assembly
• Remove the Alignment Tool Before Installing the Transmission

Why Choose Katech

The Katech ZR1/LS9X/LS9R Clutch Alignment Tool provides an application-specific aid for assembling compatible twin-disc clutches, helping simplify disc positioning during installation.

For clutch and alignment tool compatibility questions, contact Katech Technical Sales at 586-791-4120.
